Upgrading questions

Hi,

I plan to upgrade my NPM to version 12. Would like to check do I need to upgrade the Orion platform before I can upgrade the NPM or I only need upgrade NPM?

Below is the module I have.

Orion Platform 2013.2.1

SAM 6.0.2

IPAM 4.1

NCM 7.2.2

NPM 10.6.1

NTA 4.0.1

UDT 3.0.2

IVIM 1.9.0

VNQM 4.1

If I upgrade NPM, do I need to upgrade others module as well or they can remain current version?

Please give some advise. Thank you very much in advance.

Update

---------------

Found a site call SolarWinds Product Upgrade Advisor. Insert my module and found the recommended installation steps. It recommended me to upgrade my server OS to either MS Windows Server 2012 or MS Windows Server 2008 R2 SP1.

Currently I am using MS Windows Server 2008 R2. Is it still possible to upgrade the Orion module without upgrade the OS ?

Find more posts tagged with

installer

solarwinds upgrade

sql database

npm 12.1

ms server

Accepted answers

shuth

You're going to need to upgrade all of the modules (and with a lot of step-upgrades) to get to the latest version. Did the Product Upgrade Advisor spit out the steps (if you deselect the server OS)? I input your versions and it said it was too complex! I can probably work it out manually if it didn't provide a path. Orion and IVIM will update automatically as you install the other modules (i.e. upgrading NPM will also upgrade the Orion Platform version).

NPM 12.0.x is not supported on Windows Server 2008 R2 without SP1 (NPM 12.0.1 Release Notes - SolarWinds Worldwide, LLC. Help and Support ). You should be able to upgrade to NPM 12.0.1 (and equivalent modules) if you install the service pack for 2008 R2 SP1.

The newest versions currently in release candidate (RC) no longer supports Windows Server 2008 R2 at all and SolarWinds recommend upgrading to Windows Server 2012, 2012 R2 or 2016. (See: NPM 12.1 Release Notes - SolarWinds Worldwide, LLC. Help and Support ).

All comments

shuth

zheepern

Hi Steven,

Thanks for your advise.

shuth

I went through the compatibility charts (NPM product compatibility chart - SolarWinds Worldwide, LLC. Help and Support ) and came up with the following upgrade as the advisor couldn't make a path. You might be able to skip a couple of these steps but the below path should work. This will get you to the latest versions not including the new release candidates with PerfStack.

You can also contact SolarWinds support and they will be able to assist you as well.

Upgrade NPM to 11.0.1
Upgrade SAM to 6.1.1
Upgrade NPM to 11.5.3
Upgrade SAM to 6.2.3
Upgrade NCM to 7.4.1
Upgrade NTA to 4.1.2
Upgrade IPAM to 4.3.1
Upgrade UDT to 3.2.3
Upgrade VNQM to 4.2.3 (stop here if you haven't upgraded to Windows Server 2008 R2 SP1)
Upgrade NPM to 12.0.0
Upgrade NCM to 7.5.0
Upgrade UPAM to 4.3.2
Upgrade VNQM to 4.2.4
Upgrade NPM to 12.0.1
Upgrade NTA to 4.2.1
Upgrade SAM to 6.3.0
Upgrade NCM to 7.5.1
Upgrade UDT to 3.2.4
Install all applicable hot fixes (Migrate to a new OS if you want to upgrade past here)

Hope that helps. The other option to consider is starting a new install and starting fresh (i.e. new database, new server, add all your monitored elements, etc).

zheepern

HI Steven,

I got the same steps out from the Product Upgrade Advisor too.

Should will raise an support ticket and get some help from you guys soon.

Thank you very much.

zheepern

HI Steven,

One more question. Currently I am using MS SQL server 2008 R2. Do I need to upgrade this to SP1 also ?

shuth

SQL Server 2008 R2 is supported for the current full release versions of SolarWinds (e.g. up to NPM 12.0.1).

However, the new module release candidates (NPM 12.1, SAM 6.4, etc) deprecate support for SQL 2008 or 2008 R2 and future releases will not support those versions. Check out the End of Support section in this link: NPM 12.1 Release Notes - SolarWinds Worldwide, LLC. Help and Support

rcbarr

Some thoughts being I just did a 10 hour straight upgrade. You upgrade the core when you upgrade NPM if I am not mistaken. Additionally you upgrade to NPM 12 first, then some set of other applications then NPM 12.0.1. My sequence was as follows:

Date of Assessment 01/26/2017 Current Target Version

Core Orion Platform 2015.1.3 2016.2.100

Core Orion Platform / Hotfix 1 2016.2.100 2016.2.116.2.5300 (B1007)

SAM Server and Application Monitor SLX 6.2.2 6.3.0

IPAM Orion IP Address Manager IPX 4.3 4.3.2

NPM Network Performance Monitor SLX 11.5.3 12.0.1

DPA Database Performance Analyzer 10.0.0 10.2.579

QoE Quality of Experience 2.0 2.2.0

NCM Network Configuration Manager 7.4 7.5.1

IVIM Integrated Virtual Infrastructure Manager 2.1.1 2.1.2

UDT User Device Tracker v3 UTX 3.2.2 3.2.4

Orion SDK Orion SDK 1.10

Order (We have 8 pollers, a single web server and dedicated db server) in two data centers. Active/Active

NPM v12 First (All pollers and the web server)

- NPM v12 contains Cumulative Update 5
  - Orion Platform Hotfix 4
  - NPM HotFix 1
  - NetPath HotFix 2
UDT 3.2.4 (All pollers and the web server)
NCM 7.5.0 (All pollers and the web server)
NCM 7.5.0 HotFix 2 (on poller 1 only)
IPAM 4.3.2 (All pollers and the web server)
NPM v12 to v12.0.1 (All pollers and the web server)
NPM v12.0.1 Hot Fix 1 (All Pollers)
SAM v6.3 (All pollers and the web server)
NCM v7.5.1 (All pollers and the web server)
NPM HF1
NPM HF2 (probably was inclusive, but these patches are funky installs at best)
SAM HF1
DPA

Result:

Server

NPM 12.0

UDT 3.2.4

NCM 7.5.0

NCM 7.5.0 HF2

IPAM 4.3.2

NPM 12.0.1

SAM 6.3.0

NCM 7.5.1

NPM HF1

NPM HF2

SAM 6.3.0 HF1

DPA

Poller 1

Completed

Poller 2

Completed

N/A

Completed

N/A

Poller 3

Completed

N/A

Completed

N/A

Poller 4

Completed

N/A

Completed

N/A

Poller 5

Completed

N/A

Completed

N/A

Poller 6

Completed

N/A

Completed

N/A

Poller 7

Completed

N/A

Completed

N/A

Poller 8

Completed

N/A

Completed

N/A

Web

Completed

N/A

Completed

N/A

Completed

N/A

rcbarr

Misprint above, 19 straight hours it took to upgrade 8 pollers/1 web/1 database Orion set of servers.

rcbarr

Envision having to run through the configuration wizard for EACH Poller for EACH product. FYI, do NOT run the web optimization portion of the configuration wizard if you have multiple pollers until the LAST poller, rant over.....

zheepern

Hi,

I am going to upgrade the NPM to 11.0.1 & SAM to 6.1.1 but where i can download the installer of these 2 module with specific version ?

Below are the steps I will perform. Kindly advise me if there any steps I have missed ?

1. Backup webserver and database

2. Stop services

3. Upgrade NPM and SAM

4. Start service

Thank you very much in advance.

shuth

If you log into your customer portal, under the License Management menu at the top, click on My Downloads. Select the product (NPM / SAM) and license, then in the downloads section you should have the option to download the older versions in the dropdown menu.

Roughly for the steps;

1. Backup database and snapshot SolarWinds VM (or backup server if it isn't a VM)

2. Follow upgrade path as per Product Upgrade Advisor (skip the Optimize Website step in the Configuration Wizard until the last upgrade)

The services should stop/start during the installation. Contact Support if you have any issues.

serena

How did your upgrade go?
