Does NTA work with Cisco 2960X switches?

Hi,

I'm trying to get NTA working on a 2960X switch. I've configured the switch with flow record, exporter, monitor & sampler and applied the monitor to interfaces. Looking at the flow stats on the switch it seems to be sending packets to the NTA server.

Looking at the NTA server, it's saying it's "Last received netflow - Never" , BUT I am getting random errors from the 2960 saying "invalid v9 template" and "Windows firewall turned on, but not allowing packets" . However, Windows firewall is turned OFF (on the Solarwinds server) and the invalid template error occurs at random, i.e no errors for 3 days, then 2 error msg, then nothing for another day!

As the server is showing some error messages, I presume that the switch is talking to the server, but the server seems to be ignoring the data, or some of the data is missing?

Any suggestions for what's wrong?

Incidentally I do have NTA working correctly on a couple of Nexus switches, so the NTA server is working ok.

Thanks,

Mike

Find more posts tagged with

Accepted answers

All comments

cnorborg

You might want to include your netflow config so we can have an idea of what you're doing.

2960x's only do "Netflow lite", rather than returning stats on every packet that goes through them, at the most you'll get 1 out of every 32 packets reported on, which is configurable. You might have to manually set a sampling rate too. If you go to "Manage Netflow Sources", you should see "Auto-detect: " followed by something like "no sampling" or a sampling rate. If the sampling rate here doesn't match the sampling rate you chose on your 2960x, you will have to edit it to match.

brinky

Hi Craig,

Thanks for the reply, I was really asking the question whether it worked at all, because I couldn't find any definite answers by Googling.

I gave up on the 2960X and thought I'd configure another Nexus 7K, whilst waiting for a reply to my post. After putting the config on the Nexus, I went back to the Solarwinds NTA webpage and added the Nexus to the Netflow Sources. After doing this, I noticed that the 2960X (in Netflow Sources) was now saying it was receiving Netflow ! (see screenshot)

I'm beginning to wonder if it's the "last received Netflow" column on the NTA webpage that's not updating correctly?

Also, am I correct in saying the "Traffic in" and "Traffic out" info is really coming from snmp (rather than Netflow), as i haven't configured Netflow at all on another Nexus, but it's showing traffic in and out?

Incidentally, I'm using this version of Solarwinds: Orion Platform 2013.2.0, NPM 10.6, NTA 3.11.0, IVIM 1.8.1

Thanks,

Mike

cnorborg

I have heard that there seems to be some delay in the 2960x sending out its netflow template to the receiver, maybe you ran in to that. You're definitely seeing Netflow there, but like I said, its only sampling at most 1:32 packets, so make sure the ratio is set correctly!

brinky

Hi Craig,

Thanks for the info. As you can probably guess, I'm pretty new to NTA, so please can you have a look at the config I've put on the 2960 and see if I've missed anything, or there's anything that could be done better? ( Note: real destination IP address replaced with x.x.x.x)

flow record NFSWTRecord
match ipv4 tos
match ipv4 protocol
match ipv4 source address
match ipv4 destination address
match transport source-port
match transport destination-port
collect interface input
collect flow sampler
collect counter bytes long
collect counter packets long
collect timestamp sys-uptime first
!
flow exporter NFSWExporter
description Solarwinds server
destination x.x.x.x
source Vlan100
transport udp 2055
template data timeout 60
!
flow monitor NFSWMonitor
record NFSWTRecord
exporter NFSWExporter
cache timeout inactive 120
cache timeout active 120
!
sampler NFSWSampler
mode random 1 out-of 100

interface GigabitEthernet1/0/24

ip flow monitor NFSWMonitor sampler NFSWSampler input

Any suggestions would be greatly appreciated.

Thanks,

Mike

don80061241

Hi Mike,

I am not sure if you have fixed your issue but we have a similar issue.

Our investigation discovered a Thwack message "Support for Cisco Netflow-Lite" under "NetFlow Feature requests that was updated November 2015 to say that Netflow-lite is now supported in "NTA 4.1.1"

I noticed in one of your post's with your setup that you are using version 3.1.x this may be the issue.

Regards

Don
