Last xx Events. Filtered. 10.6; 10.4.2; 9.5.1

Gob


Hi. Try to run Configuration Wizard, select Website only. After that add my resource, search by word Filtered

Last Events. Filtered.zip

Find more posts tagged with

network_monitoring

filtered

network_management

Events

resource

Accepted answers

All comments

terrys1026

I'm new to SW, so some additional directions would be helpful. I downloaded the files and installed them in locations corresponding to the filenames (with the exception of installing in subdirectories of c:inetpub\SolarWindsNPM\). Do I have to restart some part of SW to make them go?

terrys1026

I figured it out, plus received confirmation from the support team while working on another ticket.

Just put the files into the locations specified by the directory names in the zip file. You'll have a new resource that you can add to web pages. I replaced the Last xx Events page with this one on the home page and am now able to filter out noisy events that aren't important to us.

matthewbsimon

BTW, I really wanted to filter out all events that relate to interfaces tagged as 'unpluggable' - because this is how I denote desktop ports.

This can't be done with the control above, but if you make 1 small modification it will work.

Change line 37 of Orion\Controls\NewEventsReportControl.ascx.cs to read:

builder.Append("SELECT TOP (@maxRecords) NetObjectType, NetObjectID, NetObjectID2, EventID, Acknowledged, EventTime, \r\n Events.EventType as EventType, Interfaces.Unpluggable as unpluggable, Message, ISNULL(EventTypes.BackColor, 0) as BackColor \r\n FROM Events \r\n LEFT JOIN Nodes ON Events.NetworkNode = Nodes.NodeID\r\n LEFT JOIN EventTypes ON Events.EventType = EventTypes.EventType LEFT JOIN interfaces on Events.NetObjectID = Interfaces.interfaceid");

all this does is add an additional left join on the interfaces table and include the unpluggable attribute.

After that you can used a filter like:
((unpluggable is null) or (unpluggable <> 1))
which is what I use.

familyofcrowes

Will this work with Version 10?

Works great with 10.5 too.... :-)

wbrown

Working great with my v10 sp1.
Makes the "Last xx events" section usable.

As terrys1026 mentions, use "customize page" to add the new functionality to the desired page.

Thank you Gob for developing this.

esamurai

Thank-you Gob and matthew b,
It took reading all of the posts and figuring out that I could not use this to change the "Events" page. I now have the unplugged interfaces not showing up as "Up" on my Summary page's Events.filtered box.
NPM 10.1 SP1, about to try 10.2.

Federico55

Hi people,
does it work on 9.5.0 ?

I put all files in destination directory but I cannot see a new resource to add in customiza page.

Thnx to all

Federico55

Hi,

I posted message below in a new topic but a senior member
suggest to me to post it here.

Can you help me pls ?
Many thanks

^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
Hi guys and eXperts,

I downloaded a very useful tool found on this forum "Last xx Events. Filtered. For NPM 9.5.1"

and it works gracefully but I have a question.

Is this tool supporting any kind of Sql query or not ?

I am trying to filter an interface using this syntax :

(Interfaces.InterfaceName='FastEthernet4/44')

(Interfaces.InterfaceIndex='678')

(Interfaces.PhysicalAddress='000C.CE64.BB7B')

but none of this one is working.

Have you any ideas ?

Thank you in advance

Gob

Federico 55, if you want to filter events by interfaces you should to modify one line. Just read the thrid answer in this topic.

pmzwieryznski

Just installed on V10 and works GREAT! Thank you for the post!

pmzwieryznski

Just installed on V10 and works GREAT! Thank you for the post!

pmzwieryznski

Just installed on V10 and workes GREAT! Thank you for the post!

peterchacko

This looks so helpful. If i need to filter out only Critical Events, would the filter command be (EventTypes.Name='Critical')

Please advise.

Thanks

Pierre

klc2009

Thank you so much for this!

rdbaker31

Works perfectly for me in NPM v10.3.1 too. Thanks for the original post.

FormerMember

Hi there,

I realise this is an old post but hopefully someoen will see and be able to help. Just installed this as instructed and added the resource to my summary screen however i recieve the following error.

Last Events. Filtered

There was an error rendering: Last Events. Filtered » View Details

I am trying to filter the events report to include everything apart from events from interfaces marked as Unplugged and have applied the following in the filter field-(unpluggable <> 1)) . I am new to sql so please be gentle. is this all i should need to add to enable this functionality.

rgeist

I have installed this, but it is not working for me. I have just upgraded to 10.5, so do you know if this resource compatible with 10.5? All of the directories that I placed the files in were in the same location as the folders were in when I downloaded it. When I go to find it in the resources to add to a page, however, it does not show up. I have added other custom objects to NPM before, such as custom pollers, and I remember them just working and showing up when I placed the file in the directory.

Nevermind. It just showed up today after I didn't do anything to it.

FormerMember

Hi guys have managed to get this working now and it has helped make our front screen event view much more useable. However i have a question which i wonder if anyone has managed to do. The default solarwinds event summary groups the events to minimise the view space that is used(See Below).

Is there anyway of modifying this resource so it would group the filtered events in the same way?

Thanks in advance guys

ffxcity1

I have had the same thing happen in version 10.5. The new resource does not show up on the resource page. I have added it to both my main NPM server and my additional web server. I have also restarted IIS. Any ideas?

rgeist

It has been acting strangely for me. Like I mentioned, it would never show up in the resources list. Then all of a sudden when I checked back a day or two later, it was magically there. I had done absolutely nothing to it, but it just happened to show up. So I added it to my pages where I wanted them. I was happy that it finally showed up. However, I go back a day or so later and want to add it to a different page. Well, it is gone from the resource list again. My filtered event resources that I already put on the page are still there and working, so I don't know exactly what is going on with it. I have not checked to see if it is in the resource list as of recently, so I don't know if its status has changed.

Michael_P

Guys I am having some issues getting this to work in 10.5. I have copied all the files into the proper directories but I am not seeing the Last XX Events Filtered in my resource list. Any ideas what I might be doing wrong. This is something we have been wanting for a while now.

Thanks

Mike

ctopaloglu

Been using this for years. It is also working for the 10.6 RC2

kalkenneth

Is there some magic trick to get these to show up in V10.5? i opened a ticket and was told they do not support customizations

kalkenneth

i got them to work by opening the files and saving them must have something to do with time stamps or something like that

FormerMember

I have installed according to the path on v10.6. But, I do not see anything on the WebConsole. Can some one please provide more details on what to perform after the install to the appropriate folders - any deletions of other files, etc.?

Gob

Hi. Try to run Configuration Wizard, select Website only. After that add my resource, search by word Filtered

ashley.cotter

Hey man,

Any chance of getting this working on 10.7

simon.charbonneau

Installed on version 11.0.1 and it's awesome. Great job. Thanks.

familyofcrowes

Anyone put this on V12 yet?

familyofcrowes

I just tested it and it is working great so far!
