Meraki MX68CW-WW Cellular Link Monitoring

Adelazz

Hi everyone,

Is anyone able to  monitor cellular links for Meraki devices?

I have an MX68CW-WW, but am able to monitor only WAN Uplinks, Cellular link is grayed out.

This is the current Orchestrators.Meraki JSON config:

• CdpLldpInterfacesMappingJson : {    "MX68CW-WW": {        "wan0": "port1",        "wan1": "port2",        "port2": "port2",        "port3": "port3",        "port4": "port4",        "port5": "port5",        "port6": "port6",        "port7": "port7",        "port8": "port8",        "port9": "port9",        "port10": "port10",        "port11": "port11",        "port12": "port12"  }}
• DeviceWanPortsCountByModelJson: { "MX68CW-WW": 2}
• UplinksInterfacesMappingJson: {"MX68CW-WW": {"wan1": "port1","wan2": "port2"}}

maciej.sandecki

From what I see Meraki MX devices with cellular currently do not expose cellular interface via SNMP, so Solarwinds is not able to link the WAN Uplink to an SNMP interface.
